iCharger 456DUO Battery Charger
Indisponible
Description / iCharger 456DUO Battery Charger
With the iCharger 456DUO, the renowned manufacturer Junsi has completely renewed the well-known 406DUO charger technically.
The new 456DUO charger combines the advantages of the well-known Junsi iCharger 406DUO with the latest technology and thus significantly more power and new functions.
The two charging outputs are equipped with high-current resistant XT90 connectors to transfer the power permanently.
The technical data can be seen, 2200W charging power (from >40V), 1-6s LiXx cells and up to 45Amp charging current are also sufficient for large batteries with high capacity. Of course, all other battery types such as LiHV, LiIo, NiZn, PB, NiCd or NiMh batteries can be charged.
The discharge power is 140Watt total (80W per output if only one output is used), but can be increased by external load (discharge resistor) up to 2200W. Of course, the iCharger 456DUO is also capable of regenerative charging. Here, the battery capacity is fed back into the supply battery from a full flight battery, for example.
The balancer current of 4 amps total ( 2A per output) always ensures perfectly balanced cell voltages.
A USB-C PD port for charging smartphones etc (5V/3A, 9V/2A, 12V/1.5A) or for software updates is also built in. The micro SD slot can be used for logging data, but also for future updates.
New is the function "Digital Power" here an output can be used as a stabilized power supply. The output voltage can be set from 2V to 32V, the current from 1A-45A (Please note that for this an appropriate supply must be given!) )
Also integrated is a servo tester, here please note that an external power supply is necessary!
The menu navigation is almost identical to the known Junsi iCharger 308DUO, 406 DUO or 4010DUO.
A 2.8" IPS LCD display ensures good readability even in low light.
Scope of delivery: 2x XT90 socket, EC8 cable for self-assembly (counterpart connection charger)
INFO: Charging cable with XT90 connectors are NOT included in delivery
A manual in English is included with the charger in the form of a CD
All Junsi chargers of the X and DUO series are developed and approved for use in model making.
An industrial use is not intended and therefore not allowed!
All Junsi chargers may only be operated with power supplies developed for model making! No AGM batteries may be charged in the PB program!
Technical data:
| Charging current adjustable per output: | 0,05A - 45A |
| Charge current adjustable in synchronous mode: | 0,05A - 70A |
| Input voltage: | 10V - 49V DC |
| Width (mm): | 118 |
| External high current discharge asynchronous: | 1400W |
| Charging power Max. on one output: | 1400W |
| Max. Discharge power: | 140W |
| Discharge power Max. in synchronous mode: | 140W |
| Max. Voltage lead acid batteries: | 15 (2 - 30V) |
| Length (mm): | 171 |
| Accuracy balancer (depending on setting): | 1mV |
| Charging power Max Syncron: | 2200W |
| External high current discharge syncron: | 2200W |
| Max. Number of NiCd/NiMH batteries: | 25 |
| Balancer Balancing current per output: | 2A |
| Height (mm): | 57 |
| Input current limit: | 70A |
| Max. Charging current: | 70A |
| Discharge power per output: | 80W |
| Weight (g): | 920 |
| Micro SD Card Slot: | Yes |
| Power supply integrated: | No |
Plus d’information
| Marque | iCharger |
|---|
